Model | Cylinder Capacity @ 10,000 PSI (700 BAR) | Oil Capacity | Tip Clearance | Maximum Spread Distance | Cylinder Effective Area | Weight |
---|---|---|---|---|---|---|
US TON | IN3 | IN/A | IN/B | IN3 | LBS | |
EHS-1 | 1 | 0.79 | 0.39 | 3.70 | 1.00 | 5.50 |
EHS-075 | 0.75 | 3.36 | 1.26 | 11.50 | 2.25 | 27.50 |
EFS-14 | 14 | 4.78 | 0.24 | 3.19 | 2.25 | 15.8 |
EHS-1 | 1 | 0.79 | 0.39 | 3.70 | 1.00 | 5.50 |
Model | Dimensions | ||
---|---|---|---|
C | D | E | |
IN | IN | IN | |
EHS-1 | 9.05 | 2.00 | 2 |
EHS-075 | 22.00 | 2.00 | 6.18 |
EFS-14 | 11.4 | 2.62 | 5.26 |
EHS-1 | 9.05 | 2.00 | 2 |
Model | Cylinder Capacity @ 10,000 PSI (700 BAR) | Oil Capacity | Tip Clearance | Maximum Spread Distance | Cylinder Effective Area | Weight |
---|---|---|---|---|---|---|
US TON | CM3 | MM/A | MM/B | CM2 | KGS | |
EHS-1 | 1 | 12.95 | 9.91 | 93.98 | 6.45 | 2.49 |
EHS-075 | 0.75 | 55.06 | 32.00 | 292.10 | 14.51 | 12.47 |
EFS-14 | 14 | 78.33 | 6.09 | 81.02 | 14.51 | 7.17 |
EHS-1 | 1 | 12.95 | 9.91 | 93.98 | 6.45 | 2.49 |
Model | Dimensions | ||
---|---|---|---|
C | D | E | |
MM | MM | MM | |
EHS-1 | 229.87 | 50.80 | 50.80 |
EHS-075 | 558.80 | 50.80 | 156.97 |
EFS-14 | 289.56 | 66.54 | 133.6 |
EHS-1 | 229.87 | 50.80 | 50.80 |
Model | Description | Repair Sheets | Instructions | CAD | |||
---|---|---|---|---|---|---|---|
Series | Series | Series | Series | ||||
EHS-1 | - | ||||||
EHS-075 | - | ||||||
EFS-14 | - | Series A | |||||
EHS-1 | - |
